واسط ریموت کنترلر SONOFF RF BRIDGE 433MHZ

معرفی

با استفاده از این دستگاه قادر به کنترل با WiFi دستگاه هایی هستید که از طریق RF 433MHz کنترل می شوند. با استفاده از این دستگاه، بعد از شناسایی دستگاه RF 433MHz و نصب برنامه گوشی، می توانید از طریق برنامه و بدون نیاز به ریموت کنترل 433MHz دستگاه موردنظر را کنترل کنید. همه دستگاه هایی که با RF 433MHZ کار می کنند(به ویژه دستگاه های SONOFF)، با واسط ریموت RF Bridge Sonoff قابل شناسایی و کنترل اند.

Introduction

Sonoff RF Bridge 433 is an ultra low power consumption device that can convert 433.92MHz (433MHz) to WiFi. It’s a bridge between 433MHz RF and WiFi, which can be added to iOS & Android App eWeLink. Users can firstly pair 433MHz devices with the RF Remote, then add their RF Remote to the App. Therefore, users can control the 433MHz devices through App eWeLink. It’s specially designed for mobile device and IoT application.

WIFI 2.4G Characteristics

Support wireless 802.11 b/g/n/d/e/i/k/r standard

Support STA/AP/STA+AP working modes

Support WPA/WPA2, PSK and WP

Built-in TCP/IP protocol stack

Support multi-channel TCP client connection

Support Wi-Fi Direct (P2P)

Multi-queue management, make full use of 802.11e-compliant QoS priority

Adaptive rate fallback algorithm sets the optimum transmission rate and Tx power based on actual SNR and packet loss information

433.92MHz Wireless Characteristics

Complete monolithic UHF receive/transmit
Receive & transmit frequency: 433.92MHz
Receive sensitivity: -107dBm
Max transmit power: 17dBm
Transmission speed: 10kbps
Autotune without manual adjustment
Ultra low RF antenna radiation
The receiving supports fixed code encoding, like PT2260, PT2262, PT2264, EV1527, etc
Not support to learn rolling code and dynamic code
